Ai Series Continuous Filling Roll Film Sealing Machine (Disc)

Good heat dissipation performance, extending the lifespan of the motor

Keywords: Keywords:GL-160M1-16,Motors

Keywords:

This is placeholder text

Category:

Sealing Machinery

Sauce and capsules

E-mail

Message

Details

APPLICATION

WORKFLOW

PROCESS FLOW

Automatic cup placement into mold → Automatic filling → Automatic film unwinding → Automatic first sealing and cutting → Automatic second sealing and reinforcement → Automatic suction cup removal → Automatic film collection

SCOPE OF APPLICATION

●The conveyor belt filling and sealing machine is widely used in the catering, food, health products, cosmetics, daily chemicals, and pharmaceutical industries, such as packaging for products like milk tea, beverages, drinking water, soy milk, and mung bean paste.
●The machine frame is made of high-quality stainless steel and aluminum alloy.
●Electrical and pneumatic components are all from internationally renowned brands, ensuring stable performance.
●Functions: Automatic cup placement, filling, film wrapping, sealing, output, and film collection are all automated processes. Customized designs are available upon request.

TECHNICAL PARAMETERS

Machine type	JCL32-2	JCL32-4	JCL32-6	JCL32-8
packaging speed	800-1800cups/hr	1600-3600cups/hr	2400-5400cups/hr	3200-7200cups/hr
Machine voltage	110V/220V/380V
Machine power	4KW	5KW	6KW	7KW
Working pressure	0.6-0.75Mpa
Machine sive	20006501600mm	20007501600mm	20008501600mm	20009501600mm
Machine weight	400Kg	500Kg	600Kg	700Kg
